A Fast Functional Algorithm to Generate Random Latin Squares by Ignacio Gallego Sagastume

Architectural Design Architecture Contemporary 842158

What different algorithms have you developed in Scala?

Software Engineer, Ignacio Gallego Sagastume created this algorithm to help him generate Random Latin Squares. Let's find out how efficient it is and how it works!



In this blog post, I will describe briefly an algorithm I have developed in the Scala language, which is useful to generate Random Latin Squares (LSs). In fact, it is the functional, stateless and recursive version of another Java algorithm that I had done as part of my master thesis, back in 2015.
 I called this algorithm "the SeqGen (sequential-generation type) with a replacement chain conflict resolution strategy" or more succinctly "SeqGen with replacement chain", or just "the replacement chain algorithm". Its main advantage is that is faster than (by a factor of around 2) the Jacobson & Matthews' (J&M) algorithm, the most widely known and accepted algorithm in the area. On the other hand, its main disadvantage is that it is not uniformly distributed (as the J&M's), but its distribution is acceptable under certain conditions, as it is approximately uniform.

LS Definition

A Latin Square (LS) of order n, is a matrix of n x n symbols (to simplify just numbers from 1 to n), in which every symbol appears exactly once in each row and column. For example:
1 2 4 3
2 4 3 1
4 3 1 2
3 1 2 4
is a random LS of order 4.
LSs are used for many applications, for example for games, combinatorics and some cryptographic applications.
A remarkable property is that L(n), the number of different LSs of order n, is only known when n<=11. For larger orders, the number L(n) is unknown up to now, and it is so high that only upper and lower bounds can be given:
The "random"-LS part means that the numbers are "mixed" as much as possible along the matrix as if they were a face of a dice in each position. An algorithm is "uniformly distributed" if every possible LS has the same probability of being generated by the algorithm.

The Scala algorithm

We will explain a generator class, where the algorithm is divided into different methods.
We start with an empty matrix, a matrix full of 0s or nulls, as you prefer. We begin by row with index 0, extracting a random number one at a time. When we finish the row 0, we can continue with row 1, in order. As the matrix is immutable, we need a function that takes a partially completed LS with n rows filled and a row index and returns a new LS with n+1 rows completed. There is a theorem that says that this can always be done, row by row, up to the last row.
How can we model a computation like this in FP? This was the first "eureka" moment: using the foldlLeft function and the empty matrix as the base element. This is the "main" method to generate an LS:
With the 0-th index, beginning with the empty matrix ls0, we generate row 0. Similarly, with the index i-th, and an LS filled up to the row i-1, we generate row i.

The getEmptyMatrix auxiliary method is simply:

Where we generate a Vector full of a special element called "null" element. Then we create and return a vector-based implementation of an LS.

We continue with the generateRow method:
This method is just the wrapper and initialization for a recursive method:
Here we have a lot to explain. But let us explain by cases. The first condition checks if the row is completed (the base case), that is, if its length is equal to the order of the LS. If this condition holds, we return the completely generated row.

Then, if the row is incomplete, we try to generate the element in position (i,j) randomly, possibly causing a conflict (repetition) in that position with previously generated elements in the same row. If a conflict is created (there is not another possibility in that position) we trigger the resolution strategy called "replacement chain". Basically, we make room for the element elem, taking into account, that this chain of replacements can fail. So, we repeat the procedure until we can accommodate the element elem without repetitions. In that case, we can continue the generation of the element in position (i, j + 1) recursively.

We highlight here the creation of a new control structure retryUntilSucceed that repeats an operation in case of an exception, extending in a way the Scala language:
Just for the sake of completeness, we list here the generateElem method, using set operations like diff (for set subtract), intersect (for set intersection). It returns a new random element that can be positioned at the position (i, j), using the java.SecureRandom class, that is secure for cryptographic applications:
Last, here is the algorithm that makes the replacement chain, that is, the sequence of replacements to make room for the selected element:
In each recursive call, we take the previously generated and repeated element, and replace it by some other possible element in that position, taking care of not repeating elements in the column of that element. The base case of the recursion is when the updated row does not contain the newElem element, and the generation can proceed from that point.


We have seen a complete algorithm to generate Random LSs. The algorithm is very efficient and behaves better than the most widely known algorithm of J&M's. Although the Java iterative version of the replacement chain algorithm is more efficient, the Scala recursive version is more clear and less error-prone, composable, more robust and easier to test.'
This article was written by Ignacio Gallego Sagastume and posted originally on
